Production Lead Time Required for This Product

This item requires 1- to 2-week production lead time.

  • Drum Brake Axle Assembly, 71.5 Axle Track, 16.5x7.0 Brakes, 25k Beam, Straight Beam With 5 in Dia and N Spindle 1641334B009
1 1

Drum Brake Axle Assembly, 71.5 Axle Track, 16.5x7.0 Brakes, 25k Beam, Straight Beam With 5 in Dia and N Spindle 1641334B009

Drum Brake Axle Assembly, 71.5 Axle Track, 16.5x7.0 Brakes, 25k Beam, Straight Beam With 5 in Dia and N Spindle 1641334B009

$2,249.52 USD
$0.00 USD $2,249.52 USD
Sale Sold out
  • QA Part Number: AAHD-00034
  • Axle Track: 71.5" Track
  • Spindle Type: N
  • Axle Beam Rating: 25,000 lbs. Beam Rating
  • Beam Style: Straight Beam
  • Axle Beam Diameter: 5.00" Axle Diameter
  • Axle Beam Wall Thickness: 0.748" Axle Wall Thickness
  • Spindle Nuts : Precision Nut Included
  • Brake Type: Drum Brake
  • Brake Size: 16.5" x 7.0"
  • Brake Rating: 23000 lbs. Brake Rating
  • Chamber: 30/30
  • Slack Adjusters : 6"
  • Shoes: FMSI-4707
  • Cam Spline: 28 Spline
  • Cam Spline Diameter: 1.50" Spline Diameter
  • Cam Length: 24.13" Cam Length
  • Cam Covers Included: No Cam Cover
  • Dust Cover: No Dust Cover
  • ABS: Bendix ABS Sensors Included
  • Lubrication: OIL 80W-90
  • Seal: ConMet
  • Hub Cap: STEMCO 343-4009
  • Hub MFG: ConMet
  • Hub Type: Hub Pilot
  • Hub Material: Cast Iron
  • Side Fill: Yes
  • Stud: Long
  • Tone Ring: Yes 6.77" PDC
  • Drum MFG: ConMet
  • Drum Type: Cast Iron
