ABS ECU Valve Module for 4S/3M with Roll Stability

ABS ECU Valve Module for 4S/3M with Roll Stability

Out of stock

$716.05 USD
$0.00 USD $716.05 USD
Sale Sold out
  • QA Part Number: AMHD-00007
  • Vendor Part Number: 1420009
  • ECU: ZF- Wabco Trailer ABS 4S/3M
  • Brand Part Number: 4005001030
  • ABS Sensors: ABS Sensors Not Included
  • ABS Sensor Extension Cable: Extension Cable Not Included
  • Power Cable 35' FIVE PIN: Power Cable Not Included
  • ABS Indicator Lamp: ABS Indicator Lamp Not Included
  • Max. operating pressure: 188.5 psi
  • Port thread 1: 2x 3/4 - 14 Dry Seal NPTF
  • Port thread 21: 3x 3/8 - 18 Dry Seal NPTF
  • Port thread 22: 3x 3/8-18 Dry Seal NPTF
  • Port thread 3: Flap Exhaust
  • Port thread 4: 1/4" - 18 Dry Seal NPTF
  • Protection class: IP 66
  • System: 4S/3M
  • Technical specification: OE specification
  • Temperature range: -40°C to +65°C
  • Type: TCS II Premium
  • Version: Premium, VCS II
  • Voltage: 12 V
  • Size (mm x mm x mm): 225 x 134 x 152
  • UPC: 193133427872
  • GOLDHOFER: 167214
  • GREAT DANE: 40502933
  • GREAT DANE: AB84017
  • HYUNDAI: 10008471
  • INTERNATIONAL: S4005001030
  • KENWORTH: S400-500-103-0
  • MAC TRAILER: 24900142
  • MACK: 6300-4005001030
  • MANAC: 22801002
  • MANAC: 228-01002
  • PETERBILT: S400-500-103-0
  • STOUGHTON: 46040401400
  • UTILITY TRAILER: 2S4005001030
  • UTILITY TRAILER: 3-9350-075
  • UTILITY TRAILER: 3-9359-075
  • UTILITY TRAILER: 393500075
  • VANGUARD: 1ABS00013
  • VANGUARD: 2ABS00013
  • VOLVO: WAB4005001030
  • WABASH: RWW4005001030
