90-Degree Elbow, 1/4 MNPT x 1/4 PTC - KV2L07-35SF

90-Degree Elbow, 1/4 MNPT x 1/4 PTC - KV2L07-35SF

$0.00 USD
$0.00 USD
Sale
Shipping calculated at checkout.

90-Degree Elbow Fitting - KV2L07-35SF

The SMC KV2L07-35SF is a 90-degree elbow push-to-connect fitting for routing pneumatic tubing into a male threaded port. The referenced SMC chart identifies the matching KV2L07-35S configuration with 1/4 in applicable tube outside diameter and 1/4-18 NPT thread.

Specifications

  • Fitting style: 90-degree elbow
  • Applicable tube OD: 1/4 in
  • Thread: 1/4-18 NPT
  • Hex: 14.29 mm
  • Minimum flow diameter: 3.5 mm
  • Reference part: KV2L07-35S

This fitting is used where a compact right-angle pneumatic tube connection is required.
