90-Degree Elbow, 3/8 MNPT x 3/8 PTC - KV2L11-36S

90-Degree Elbow Fitting - KV2L11-36S

The SMC KV2L11-36S is a 90-degree elbow push-to-connect fitting for connecting 3/8 in pneumatic tubing to a 3/8-18 NPT threaded port. The referenced SMC chart lists the fitting with a right-angle body, 19.00 mm hex, and 5.4 mm minimum flow diameter.

Specifications

• Fitting style: 90-degree elbow
• Applicable tube OD: 3/8 in
• Thread: 3/8-18 NPT
• Hex: 19.00 mm
• Minimum flow diameter: 5.4 mm
• Reference part: KV2L11-36S

This elbow is used where a 3/8 in pneumatic line needs a compact right-angle threaded connection.
