The KV2L11-34S is a 90-degree male elbow push-to-connect fitting. The SMC Series KV2 reference chart identifies the highlighted configuration with 3/8 in applicable tube outside diameter and 1/8-27 NPT thread. It is used where a compact right-angle pneumatic tube connection is required.
Product Details
SKU 1350049
Brand: SMC
Part Number: KV2L11-34S
Product Type: 90-Degree Male Elbow
Applicable Tube OD: 3/8 in
Thread: 1/8-27 NPT
Hex: 19.00 mm
D1: 17.9 mm
D2: 18.1 mm
L1: 26.2 mm
L2: 26.6 mm
Minimum Flow Diameter: 5.4 mm
Common Uses
Right-angle pneumatic tube connection
Height control valve fitting service
Truck and trailer air system maintenance
Verify tube size, thread size, and original part number before ordering.
