Straight Male Connector - KV2H11-35S

The SMC KV2H11-35S is a straight male push-to-connect pneumatic fitting. The referenced SMC chart identifies the highlighted configuration with 3/8 in applicable tube outside diameter and 1/4-18 NPT thread.

Specifications

  • Fitting style: straight male connector
  • Applicable tube OD: 3/8 in
  • Thread: 1/4-18 NPT
  • Hex: 17.46 mm
  • Overall length: 33.2 mm
  • Minimum flow diameter: 5.4 mm

Use this fitting where a 3/8 in pneumatic tube must connect to a 1/4-18 NPT threaded port.
