Male Connector, 1/4 MNPT x 1/4 PTC - KV2H07-35S
Male Connector, 1/4 MNPT x 1/4 PTC - KV2H07-35S
Regular price
$0.00 USD
Regular price
Sale price
$0.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Straight Male Connector - KV2H07-35S
The SMC KV2H07-35S is a straight male push-to-connect fitting for connecting 1/4 in pneumatic tubing to a 1/4-18 NPT threaded port. The reference chart lists the fitting as a straight male connector with compact body dimensions and a minimum flow diameter of 3.5 mm.
Specifications
- Fitting style: straight male connector
- Applicable tube OD: 1/4 in
- Thread: 1/4-18 NPT
- Hex: 14.29 mm
- Overall length: 22.7 mm
- Minimum flow diameter: 3.5 mm
Use this connector for direct pneumatic tube-to-thread connections where KV2H07-35S is specified.
